Stainless Steel cable netting for Safety Barrier and Fall Protection

Stainless Steel cable netting  for Safety Barrier and Fall Protection
Stainless Steel cable netting  for Safety Barrier and Fall Protection Stainless Steel cable netting  for Safety Barrier and Fall Protection Stainless Steel cable netting  for Safety Barrier and Fall Protection Stainless Steel cable netting  for Safety Barrier and Fall Protection Stainless Steel cable netting  for Safety Barrier and Fall Protection

大画像 :  Stainless Steel cable netting for Safety Barrier and Fall Protection

商品の詳細:
起源の場所: 河北省、中国
ブランド名: Velp
お支払配送条件:
最小注文数量: 10平方メートル
価格: USD18~190
パッケージの詳細: 木製ケース
受渡し時間: 15~30営業日
支払条件: 、T/T、L/C、Western Union
供給の能力: 10000SQM

Stainless Steel cable netting for Safety Barrier and Fall Protection

説明
製品名: ステンレススチールロープメッシュ キーワード: ワイヤー ロープの網
材料: ステンレス鋼304 316 ロープの直径: 1.0mm 1.5mm 2.0mm 3.0mm など
構造: 7*7 7*19 メッシュ開口部: 20*20mm 38*38mm 60*60mm など
応用: 鳥小屋のネット、動物の囲いなど。 技術: 織物
色: シルバーグレーブラックオレンジグリーンカスタムカラー 包装: 木製ケース
ハイライト:

stainless steel safety barrier netting

,

fall protection cable netting

,

stainless steel rope wire mesh

Stainless Steel Cable Netting for Safety Barrier and Fall Protection
Stainless steel cable netting, also known as stainless steel rope mesh or flexible cable mesh, is a high-performance metal mesh product woven from high-quality stainless steel wire ropes through advanced ferrule crimping or interwoven knotting technology. Recognized globally for outstanding corrosion resistance, superior tensile strength, flexible structure, and long service life, this versatile material combines practicality, safety, and aesthetics. It serves as the preferred solution for architectural decoration, animal protection, safety guardrails, marine engineering, and various other applications, with customizable specifications to meet diverse project requirements.
Core Material and Craft Features
Premium Stainless Steel Material Selection
We utilize AISI 304, 316, and 316L stainless steel as core raw materials, each selected for specific environmental conditions:
  • 304 Stainless Steel: Cost-effective with excellent resistance to daily corrosion and UV radiation, ideal for indoor applications, standard outdoor environments, and general breeding facilities
  • 316/316L Stainless Steel: Enhanced with molybdenum elements for superior corrosion and salt spray resistance, specifically designed for harsh environments including coastal areas, chemical plants, marine engineering, and high-humidity breeding farms
All materials develop a dense oxide surface film that effectively resists acid, alkali, chemical erosion, and rust while maintaining structural stability across temperatures from -60℃ to 300℃.
Advanced Weaving Technology
Our cable netting utilizes stainless steel wire ropes with 7*7 or 7*19 core structures (multiple steel wires stranded to form single ropes), processed through two primary methods:
  • Ferrule Type (X-Tend Mesh): Fixed with stainless steel ferrules for neat structure, high connection strength, and stable mesh dimensions, ideal for large-area guardrails and architectural facades
  • Interwoven/Knotting Type: Hand-woven without additional connectors, offering exceptional flexibility and adaptability to irregular shapes including curved walls and animal enclosures
Stainless Steel Cable Netting Specifications
Rope Diameter Structure Minimum Break Loading
1.0mm 7*7 0.6KN
1.5mm 7*7 1.5KN
2.0mm 7*7 2.5KN
3.0mm 7*9 5.3KN
Product Gallery
